Bently Nevada 133811-03 3500/62 Process Variable Monitor

SKU: 133811-03

Technical specifications

  • Manufacturer: Bently Nevada

  • Condition:New with Original Package

  • Product Type: 3500/62 Process Variable Monitor

  • Country of Origin: USA

  • Payment:T/T, Western Union

  • Shipping port: Xiamen

  • Warranty: 12 months

By submitting a request for this item, you confirm that you have reviewed and accepted our Terms & Conditions. Please note that all transactions will be processed offline.

100% Original and Authentic
100% Brand New, Ready to ship
Support Refund, 7X24h Service
1-Year Warranty on All Products

Help us reach more people! Share this product with your network and show your support!

Product Description

The 3500/62 Process Variable Monitor is a 6-channel monitor for processing machine critical parameters that merit continuous monitoring, such as pressures, flows, temperatures, and levels.  The monitor accepts +4 to +20 mA current inputs or any proportional voltage inputs between -10 Vdc and +10 Vdc.  It conditions these signals and compares the conditioned signals to user-programmable alarm setpoints.

The Bently Nevada 133811-03 3500/62 Process Variable Monitor is a critical component in industrial automation systems, designed to monitor and control process variables in real-time. It is specifically built to integrate seamlessly with Bently Nevada's 3500 Series machinery protection and condition monitoring systems. The 3500/62 provides a reliable solution for monitoring various process variables such as pressure, temperature, and flow, ensuring optimal performance and protecting equipment from damage. With advanced features such as alarm and trip setpoints, signal conditioning, and flexible output configurations, the 3500/62 is ideal for use in critical industrial applications.

Technical Specifications

  • Model Number: 133811-03
  • Input Signal Types Supported:
    • 4-20 mA
    • 0-10 VDC
    • Custom input ranges (depending on configuration)
  • Output Signals:
    • Analog output: 4-20 mA, 0-10 VDC, or user-defined ranges
    • Alarm and trip outputs
  • Supply Voltage: 20-30 VDC
  • Power Consumption: 2 W (typical)
  • Temperature Range:
    • Operating: -40°C to 85°C (-40°F to 185°F)
    • Storage: -40°C to 85°C (-40°F to 185°F)
  • Dimensions: 7.8 x 10.2 x 2.5 inches (19.8 x 25.9 x 6.4 cm)
  • Weight: 0.5 kg (1.1 lbs)
  • Mounting: Rack or panel mountable
  • Approvals: CE, UL, RoHS Compliant
  • Communication Protocol: Compatible with 3500 Series monitoring systems, supporting integration into plant-wide monitoring solutions.



Other Attributes

  • Series: 3500 System
  • Country of Origin: USA
  • Lead Time: In Stock, 2 Working Days
