Bently Nevada
Bently Nevada 330709-000-040-10-02-05 3300 XL 11 mm Proximity Transducer System In Stock
Bently Nevada 330709-000-040-10-02-05 3300 XL 11 mm Proximity Transducer System In Stock
Manufacturer: Bently Nevada
-
Part Number: 330709-000-040-10-02-05
Condition：New with Original Package
Product Type: 3300 XL 11 mm Proximity Transducer System
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The Bently Nevada 330709-000-040-10-02-05 is part of the 3300 XL series of 11mm Proximity Transducer Systems, designed for reliable and precise vibration and displacement measurement in rotating machinery. This system is engineered to provide accurate performance in harsh industrial environments, making it ideal for critical applications in various industries, including oil and gas, power generation, and manufacturing. Its compliance with API 670 standards ensures high reliability and effective monitoring of machinery conditions.
The 3300 XL 11 mm Proximitor Sensor is designed to replace the 7200-series 11 mm and 14 mm Transducer Systems. When upgrading from the 7200-series system to the 3300 XL 11 mm system, every component must be replaced with 3300 XL 11 mm components. In addition, the monitoring system must be updated. If using a 3500 Monitoring System, an updated version of the configuration software that lists the 3300 XL 11 mm Transducer System as a compatible option is required. Existing 3300 Monitoring Systems may need a modification.
Technical Specifications
- Model: 330709-000-040-10-02-05
- Probe Tip Diameter: 11mm
- Probe Length: 40 feet (12.2 meters)
- System Cable Length: 10 feet (3.05 meters)
- Mounting Thread: 3/8-24 UNF
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Measurement Range: 2 mm (80 mils)
- Frequency Response: 0 to 10 kHz
-
Operating Temperature:
- Probe: -35°C to +177°C (-31°F to +350°F)
- Extension Cable: -51°C to +177°C (-60°F to +350°F)
- Proximitor Sensor: -35°C to +100°C (-31°F to +212°F)
- Storage Temperature: -51°C to +177°C (-60°F to +350°F)
- Output Signal: 4-20 mA
- Power Supply Voltage: -24V DC to -30V DC
- Maximum Cable Length: 100 feet (30.48 meters)
- Connector Type: Miniature coaxial connector
- Linear Range: 80 mils (2.0 mm)
-
Recommended Gap: 50 mils (1.27 mm)
Other Attributes
- Series: 3300 System
- Country of Origin: USA
- Lead Time: In Stock, 2 Working Days
