Bently Nevada
Bently Nevada 330906-02-12-10-12-00 3300 XL NSv Proximity Transducer System In Stock
Bently Nevada 330906-02-12-10-12-00 3300 XL NSv Proximity Transducer System In Stock
Manufacturer: Bently Nevada
-
Part Number: 330906-02-12-10-12-00
Condition：New with Original Package
Product Type: 3300 XL NSv Proximity Transducer System
-
Country of Origin: USA
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
The Bently Nevada 330906-02-12-10-12-00 is part of the 3300 XL NSv (Narrow Side View) Proximity Transducer System, designed for reliable, precise vibration and displacement measurements in industrial applications. It is used extensively for monitoring critical machine conditions such as shaft vibration, thrust position, and speed in various industries, including oil and gas, power generation, and other heavy industrial sectors.
This proximity transducer system is specifically optimized for applications with tight installation spaces or where standard transducers cannot be used due to size restrictions.
The primary uses for the 3300 XL NSv Transducer System are for areas where counter bore, sideview, or rearview restrictions limit the use of standard Bently Nevada 3300 and 3300 XL 5 and 8 mm Transducer Systems. It is also ideal for small target applications, such as measuring radial vibration on shafts smaller than 51 mm (2 in) or axial position on flat
targets smaller than 15 mm (0.6 in). It is primarily used in the following applications on fluid-filmed bearing machines where a small shaft or reduced side-view is present:
Technical Specifications
- Model: 330906-02-12-10-12-00
- System Type: Non-contact Proximity Transducer System
- Probe Type: Narrow Side View Probe (NSv)
- Probe Length: 10 ft (3.0 m)
- Connector Type: Standard 90-degree connector
- System Length: 12 ft (3.6 m)
- Calibrated Range: 0.25 mm (10 mils)
- Frequency Response: 0 to 10 kHz
-
Temperature Range:
- Operating: -35°C to +177°C
- Storage: -50°C to +177°C
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Power Supply Voltage: -24V to -30V DC
- Output Signal: 4-20 mA
- Linear Range: 0.5 mm (20 mils)
- Mounting Options: Threaded or unthreaded probe options for flexible installation
-
Compliance: Meets API 670 requirements for machinery protection systems.
Other Attributes
- Series: 3300 System
- Country of Origin: USA
- Lead Time: In Stock, 2 Working Days
