Honeywell LG1093AA03 In Stock Flame Sensor, 3/4"NPT Connection with 16FT Cable with Factory Sealed Ready to Ship
Honeywell LG1093AA03 In Stock Flame Sensor, 3/4"NPT Connection with 16FT Cable with Factory Sealed Ready to Ship
Manufacturer: Honeywell
-
Part Number: LG1093AA03
Condition：New with Original Package
Product Type: Flame Sensor
Payment:T/T, Western Union
Shipping port: Xiamen
Warranty: 12 months
Product Description
UV Flame Monitor System
Industrial power generation gas turbine installations demand the superior protection provided by the Honeywell UV Flame Monitoring System. The Honeywell flame monitor system detects the ultraviolet radiation emitted by a hydrocarbon flame and produces an output signal to indicate a flame or noflame condition. This system has delivered proven performance on General Electric (and GE licensee) gas turbines for more than 35 years. Land-based and off-shore applications include power generation, pumping stations, shipboard power generation among other industrial uses. A variety of sensor
types, amplifier types and sensor cable lengths are available
| LG1093 Flame Sensor Characteristics | |||
| LG1093AA | LG1093AB | LG1093AC | |
| Mounting Interface | 3/4 inch internal NPT | 1.73 inch O.D.by 0.14 inch wide flange |
1.73 inch O.D.by 0.14 inch wide flange |
| Contro Panel Connection |
Teflon shielded cable with one inch external conduit thread. |
Two pin connector | Two conductor armored cable |
| Operating Temperature | 40°F to +350F | -40F to +350°F | -40°F to +350°F |
| Window Pressure Rating | 150 psig at 400°F | 6.3psig | 6.3psig |
| Special Certifications | Factory Mutual: Explosion Proof Class I Divisions 1 and 2, Groups B,C and D CE Mark: EMC Directive 89/336/EEC ATEX Directive 94/9/EC Il 2G EEx d IIAT3 or EEx d IIC T3 Models AA34/35/36/44/45/46 |
None | CE Mark: EMC Directive 89/336/EEC ATEX Directive 94/9/EC Models AC01.…09 |
| Cable Lengths | AAx4:16ft(4.9m) AAx5:42ft(12.8m) AAx6:61ft.(18.6m) |
AC01/AC02:9ft.(2.7m) AC05:24ft.(7.3m) AC09:60ft (18.3m) |
|
Other Attributes
- Series: Honeywell UV Flame Monitoring System
- Country of Origin: USA
- Lead Time: In Stock, 2 Working Days
